RTR-50
Metro’s RTR-50 is a highly versatile heavy-duty rotator, engineered to deliver the ideal balance between overall size and serious lifting capacity.
With 360° continuous rotation and an advanced sliding boom system, the RTR-50 can reach, lift, and recover vehicles in virtually any scenario you encounter on the job.
Whether you’re dealing with complex recovery sites, limited access areas, or heavy lifting demands, the RTR-50 provides the power, reach, and control you need.
A true heavy-duty rotator built to perform without compromise.
Unit weight without chassis: 20,700 kg (45,600 lbs)
Standard Features
- 5476 mm (216’’) Cab to centre of tandem standard steel body
- 2 x 25 ton (55,000 lbs) winches
- 1 set of frame fork holders and 4 sets of frame forks
- Safety chains
- Frame fork and chain racks
- Chrome door handle
- Air and 12V/24V outputs
- Non slide configuration
Options
- Complete wireless remote control
- Proportional remote control
- Slide configuration
- 2 additional 20 ton (44,000 lbs) winches
- 609 mm (24″), 762 mm (30″), 914 mm (36″), 1219 mm (48″), 1828 mm (72″) tunnel box
- Tailboard controls
- Extra frame forks
- Wheel lift receivers for single / double tires
- Full recovery tool package
- Custom storage system
- Aluminum / Composite body
- European body style
- Gravel guard undercoating finish
- Front push bumper
- Front winch and Drag winch
- XP, X-shape side puller
- A-arm style side winches
- Steel core rope
- Chrome hand rails
- In cab controls
- Full size LED light bar
- LED – working lights, strobe lights, lights inside toolbox
- Custom painting
- Installation services and extended warranty
- Tow operators education & training
Specifications
Boom Rating
- Retracted Capacity (at max angle), kg (50000)
- Extended Capacity (at max angle), kg (12500)
- Max. Lift Angle, deg (70)
- Max. Hook Height, mm (1307)
- Reach Past Tailboard, mm (6947)
Wrecker Boom Winch Rating
- Winch Type (on 1st layer) (Planetary)
- Quantity (on 1st layer), pc(s)(2)
- Pulling force (on 1st layer), kg (30000)
- Winch Type (on 2nd layer) (Planetary)
- Quantity (on 2nd layer), pc(s) (2)
- Pulling force (on 2nd layer), kg (20000)
Wrecker Boom Wire Rope (on 1st layer)
- Work Load Limit (each line), kg (7600)
- Construction (6×36 IWR)
- Diameter, mm (22)
- Length, m (60)
Wrecker Boom Wire Rope (on 2nd layer)
- Work Load Limit (each line), kg (6200)
- Construction (6×36 IWR)
- Diameter, mm (19)
- Length, m (60)
Euro Low Underlift Rating (Optional)
- Retracted Capacity (on forks), kg (22500)
- Retracted distance to the forks, mm (1844)
- Extended Capacity (on forks), kg (5600)
- Extended distance to the forks, mm (3700)
- Negative tilt angle, deg (8)
- Tow Rating, kg (36000)
Drag Belly Winch Rating
- Winch Type (Planetary)
- Quantity, pc(s) (1)
- Pulling force, kg (10000)
Drag Belly Wire Rope
- Work Load Limit (each line), kg (6200)
- Construction (6×36 IWR)
- Diameter, mm (19)
- Length, m (60)
Tire Lift Rating
- Lifting Capacity (each arm), kg (5600)
- Lifting Capacity (total), kg (11300)
- Towing Capacity, kg (36000)
5th wheel adapter
- Lifting Capacity, kg (6800)
- Towing Capacity, kg (11300)
Pintle Hook Ball Hitch
- 2″ (50mm) Ball Hitch, kg (4500)
- Pintle Hook, kg (7200)
- Gross Trailer Weight Max. vertical Load, kg (1300)
Hydraulic System
- Operating Pressure, bar (203)
- Hydraulic Line Burst Pressure, bar (1320)
- System Flow, LPM (80)
- System Capacity, L (150)
- System Capacity, L (253)
- Reservoir Capacity, L (330)
Type of Oil
- -17°C to 40°C / 0°F to 104°F (Mobilfluid 424)
- -40°C to -17°C / -40°F to 0°F (Mobile DTE 10 Excel 32M)
Vehicle Recommendations
- Front axle(s) weight (min) (1×6600)
- Rear axle(s) weight (min) (3×10400)
- Recommended GVW (min), kg (32000)
- Recommended Tire Size (11R24.5)
- Clear CA, mm (5377)
Unit Weight, kg (19490)
×
![]()
