INT-5
The INT-5 is a true workhorse, built to deliver the power and performance your daily operations demand—and ready to take on even more.
Engineered for reliability and efficiency, this model provides outstanding value while keeping operating costs low.
Whether you’re starting a new fleet or expanding an existing one, the INT-5 is the perfect choice to increase capability without increasing your budget.
Strong, dependable, and economical—everything you need in a light-duty wrecker.
Unit weight without chassis: 1,650 kg (3,600 lbs)
Standard Features
- 1620 mm (64”) Cab to Axle steel body
- 4 ton (8,800 lbs) winch
- Driver and passenger side manual controls
- Wheel scoops
- Fork receivers and 50 mm (2”) frame forks
- Safety chains
Options
- Tunnel box 610 mm (24’’)
- Dollies
- Extra 4 ton (8,800 lbs) winch
- Rear anchors mounted on the under lift
- Remote control
- In cab controls
- Extra frame forks
- Custom paint in 2 or more colors
- Extra tools (snatch blocks, chains, straps, hooks)
- Aluminum body
- LED working lights
- LED strobe lights
- LED lights inside toolbox
- Installation services and extended warranty
- Tow operators education & training
Specifications
Boom Rating
- Retracted Capacity (at max angle), kg (5000)
- Extended Capacity (at max angle), kg (1500)
- Max. Lift Angle, deg (32)
- Max. Hook Height, mm (2456)
- Reach Past Tailboard, mm (642)
Wrecker Boom Winch Rating
- Winch Type (on 1st layer) (Worm)
- Quantity (on 1st layer), pc(s) 1(2)
- Pulling force (on 1st layer), kg 4000(8000)
- Winch Type (on 2nd layer) (1457)
Wrecker Boom Wire Rope (on 1st layer)
- Work Load Limit (each line), kg (1300)
- Construction (7×19)
- Diameter, mm (11)
- Length, m (30)
Underlift Rating
- Retracted Capacity (on forks), kg (3600)
- Retracted distance to the forks, mm(785)
- Extended Capacity (on forks), kg (2400)
- Extended distance to the forks, mm (1731)
- Negative tilt angle, deg (11)
- Tow Rating, kg (3400)
Front Side Puller
- Winch Type (Worm)
- Quantity, pc(s) (1)
- Pulling force, kg (4000)
Drag Belly Wire Rope
- Work Load Limit (each line), kg (1300)
- Construction (7×19)
- Diameter, mm (11)
- Length, m (30)
Hydraulic System
- Operating Pressure, bar (203)
- Hydraulic Line Burst Pressure, bar (1320)
- System Flow, LPM (60)
- System Capacity, L
- System Capacity, L
- Reservoir Capacity, L (25)
Type of Oil
- -17°C to 40°C / 0°F to 104°F (Mobilfluid 424)
- -40°C to -17°C / -40°F to 0°F (Mobile DTE 10 Excel 32M)
Vehicle Recommendations
- Front axle(s) weight (min) (1×3000)
- Rear axle(s) weight (min) (1×4500)
- Recommended GVW (min), kg (7000)
- Recommended Tire Size (R20)
- Clear CA, mm (1620)
Unit Weight, kg (1273)
×
![]()
