DTU-35
The MDTU-35 builds on everything operators love about our 20-ton unit—now with greater strength, versatility, and recovery performance.
Equipped with an extendable boom for essential recovery operations and dual winches engineered for heavier pulls, the MDTU-35 delivers confidence in every job. Whether you’re upgrading an existing heavy-duty fleet or stepping into the heavy towing and recovery industry, the MDTU-35 provides the perfect balance of power, reliability, and value.
A true workhorse designed to take your capabilities to the next level.
Standard Features
- Standard steel body
- Frame fork holders
- Frame forks racks
- Chain racks
- 4 sets of frame forks
- Chrome door handle
- Driver and passenger side manual controls
- Safety chains
- Headache chain rack
Options
- Wireless Remote Control, non-proportional
- Extra frame forks
- Wheel lift receivers for single / double tires
- Full recovery tool package
- Custom storage system
- Gravel guard undercoating finish
- Front push bumper
- XP, X-shape side puller
- Extendable rear jack legs
- In cab controls
- Full size LED light bar
- Wiring harness and junction box, Cab switches panel
- Air and Electrical outputs at the tailboard
- LED – working lights, strobe lights, lights inside toolbox
- Custom painting
- Installation services and extended warranty
- Tow operators education & training
Specifications
Boom Rating
- Retracted Capacity (at max angle), kg (35000)
- Extended Capacity (at max angle), kg (11300)
- Max. Lift Angle, deg (41)
- Max. Hook Height, mm (4665)
- Reach Past Tailboard, mm (752)
Wrecker Boom Winch Rating
- Winch Type (on 1st layer) (Planetary)
- Quantity (on 1st layer), pc(s) (2)
- Pulling force (on 1st layer), kg (20000)
Wrecker Boom Wire Rope (on 1st layer)
- Work Load Limit (each line), kg (6200)
- Construction (6×36 IWR)
- Diameter, mm (19)
- Length, m (60)
Underlift Rating
- Retracted Capacity (on forks), kg (15000)
- Retracted distance to the forks, mm(2196)
- Extended Capacity (on forks), kg (7000)
- Extended distance to the forks, mm (3640)
- Negative tilt angle, deg (13)
- Tow Rating, kg (36000)
Tire Lift Rating
- Lifting Capacity (each arm), kg (5600)
- Lifting Capacity (total), kg (11300)
- Towing Capacity, kg (36000)
5th wheel adapter
- Lifting Capacity, kg (6800)
- Towing Capacity, kg (11300)
Pintle Hook Ball Hitch
- 2″ (50mm) Ball Hitch, kg (4500)
- Pintle Hook, kg (7200)
- Gross Trailer Weight Max. vertical Load, kg (1300)
Hydraulic System
- Operating Pressure, bar (203)
- Hydraulic Line Burst Pressure, bar (1320)
- System Flow, LPM (80)
- System Capacity, L (57)
- Reservoir Capacity, L (80)
Type of Oil
- -17°C to 40°C / 0°F to 104°F (Mobilfluid 424)
- -40°C to -17°C / -40°F to 0°F (Mobile DTE 10 Excel 32M)
Vehicle Recommendations
- Front axle(s) weight (min) (1×6600)
- Rear axle(s) weight (min) (2×10400)
- Recommended GVW (min), kg (27500)
- Recommended Tire Size (11R22.5)
- Clear CA, mm (3717)
Unit Weight, kg (7038)
×
![]()
